Water & Rain

• 3/4 Inch Rain Head - Chunky to fine rain at pressure​​​​​​​​​

  • Throw: 3-4m wide; square pattern

  • Vertical Rain at 4-5m elevation

  • Ideal for: directly about action

  • Max flow: 80lt/min

​

• 1 Inch Rain Head - Chunky to fine rain at pressure​​​​​​​​​​​​​

  • Throw: 4-6m wide; square pattern

  • Vertical Rain at 6m elevation

  • Ideal for: directly about action

  • Max flow: 180lt/min

​

• ​1 Inch Bird Mouth - Chunky to fine directional rain ​​​​

  • Throw: 4-6m wide; directional

  • Vertical Rain at 6m elevation

  • Max flow: 180lt/min

  • Ideal for: Sheeting rain off eaves from outside of set; between camera and cast

​​​​​

• ​1 1/2 Inch Rain Head  - Chunky rain​​

  • Throw: 6-8m wide; square pattern

  • Vertical Rain at  8m elevation

  • Max flow: 260lt/min

​​​

• ​1 1/2 Inch Spinner - Chunky to fine rain at pressure​​​​​

  • Throw: 7-9m wide; square pattern

  • Vertical Rain at  8m elevation

  • Max flow: 260lt/min



​

• ​2 1/2 Inch Spinner  - Chunky to fine rain at pressure​​​

  • Throw: 9-12m wide; square pattern

  • Vertical Rain at 8m elevation

  • ​Max flow: 480lt/min

​

Variety of other drip rigs, nozzles, water patterns and spouts are available for every application:

• V-Shapes

• Drip Rigs

• Circlar

• Spinning

• Spray heads

• Fountain spouts

• Sheeting rain

• Water features

• Waterfalls

Send an enquiry and MFX can get back to you with a solution.

•  3/4 Inch and 1 Inch FIREFIGHTING nozzles

  • Max flow 40lt-80lt/minute​

  • Throw: Max 25m jet to spray

  • Ball-valve taps

  • Female Camlock fitting

​

• 1 1/2 Inch FIREFIGHTING nozzles

  • Max flow 60-120lt/minute​

  • Throw: Max 40m - jet to spray

  • Ball-valve taps

  • 1 1/2" universal STORZ fittings available

​

• 2 Inch FIREFIGHTING branches

  • Max flow 60-180lt/minute​

  • Throw: Max 60m jet to spray

  • Branch handles

  • 1 1/2" and 2 1/2" universal STORZ fittings available

​

• 3 Inch FIREFIGHTING monitor & nozzle

  • Max flow 180 - 900 lt/minute​

  • Throw: 6-storey vertical jet to spray

  • Double feed monitor stand OR 3" BSP fitting for specialist applications

  • 2 1/2" universal STORZ fittings available

​

• High pressure water mist/vapour

• Produces a fines mist that can be manipulated with air; offers an alternative to CO2 effects and more

• Petrol or 240V powered systems available

• Nozzles & hosing regularly serviced and checked

• Contained in a skid for easy transport

• Requires SFX TECHNICIAN to install and operate

• Actor safe with proper measures

• 5m and 6m extension

• ​Suitable for use with 3/4" Rain bars and 1" Nozzles

• 3/4" Rain Bars reach 4m (when counterweighted)

• 3/4" Rain Bars reach 5-6m when used w/boom kit

• 4-stage manual lift stand

• Industry Standard

• Spigot adapters for all 3/4" Rain Bars

• Extendable arm to level stand at height

• Hollywood, Big Ben and more rigging options available

​

• 6m extension wide base stand

• Sturdy wheels for rolling heavier rigs

• 5-stage crank lift stand

• Industry Standard

• Supports 1" - 1  1/2" RAIN BARS (see below); reaches up to 4.5m when using with  1  1/2" rain bar & boom kit (Requires SFX TECHNICIAN or SFX RIGGER)

• Supports DISCO TRUSS RIG (see below) with 1  1/2" spinner or Rain Head; reaches up to 7m from stand  (Requires SFX TECHNICIAN or SFX RIGGER)

• Hollywood, Big Ben and more rigging options available

• 10m extension wide base stand

• 5-Stage crank lift stand

• Industry Standard

• Spigot adapters for all larger 1  1/2" RAIN BARS  (Requires SFX TECHNICIAN or SFX RIGGER)

• Supports DISCO TRUSS RIG with 9m extension  (Requires SFX TECHNICIAN or SFX RIGGER)

• Also suitable for 3/4" Rain Bars and Nozzles

• Extendable arm to level stand at height

• Hollywood, Big Ben and more rigging options available

RAIN BARS

• 3/4 Inch

  • 4-6m reach from stand​​

  • single or dual heads

  • rigged with spigot for all our stands

  • requires counterweight​​​​​​​​​​​​​​​​

​

• ​1 Inch

  • 5-6m reach from single heads

  • single or dual heads

  • rigged with spigot for all our stands

  • requires counterweight​​​

​​

• 1  1/2 Inch​

  • 6-8m reach from single heads

  • single or dual heads

  • Requires specialist rigging or access equipment

​​​​​

DISCO TRUSS

• Collapsible system

• Ideal for hard to get to locations and limited access sets​

• Between 5-9m from stand to rain head

​​​​

SPECIALIST RAIN RIGS

• Enquire about our large specialist rigging solutions for coverage over large areas in all rain conditions and effects

• All our provided hose and fittings are manufactured to endure tough conditions and are regularly tested to ensure safe application on set and around sensitive or electronic equipment

• We also ensure that hoses are cleaned and handled with the safety of cast and crew in mind - ensuring potable water quality is maintained when required on the receiving end off any water effect and firefighting safety is failsafe standard

​

• Available in durable, firefighting standard materials:

  • 3/4" Camlock (5m, 10m & 15m Black)

  • 1  1/2" Storz (5m, 10m, 15m, 20m, 30m - Black and Red)

  • 2  1/2" Storz (5m, 10m, 15m, 20m, 30m - Black and Red)

  • 1 1/2", 2", 3" Suction Hose (1m, 2m - Camlock and Storz)

• Any and all fittings between water source, pump and outlet available

• 240V to 3PHASE

• Water provision from light a drizzle or wetdown to drenching rain and raging torrents

• With a wide range of in-house pumps, heaters and filtration systems + many more solutions from our local providers, we can help you match your application to the correct pump and output system, with all the fittings in between

• Semi-permanent set installations through one of our experienced techs/partners or compact mobile systems for multiple sets.

• Reliable Wet Down Carts, trucks and tanks available through our service providers and outside vendors - let us know your requirements and restrictions and we can match your production with the right solution
